Standard design

The sanitary centrifugal pump has large internal round chamfer and cleaning type seal.

Sanitary Self-priming Centrifugal Pump specially designed for CIP has the stainless steel protection cover used for protecting the motor, and the equipment is supported by four adjustable feet.

Shaft seal

The GKH sanitary centrifugal pump is provided with a set of externally mounted single end mechanical seal or water injection mechanical seal.

The static ring of the mechanical seal is made of stainless seal, silicon carbide or tungsten alloy.

The dynamic ring is made of stainless seal, carbon, graphite or tungsten alloy.

The seal ring of the water injection type seal is a durable lip seal. The series of pump products can also be equipped with the double end mechanical seal.

Application

The GKH sanitary centrifugal pump is a kind of highly-efficient and economic centrifugal pump.

In addition to meeting the requirements for sanitation and soft treatment to products, it also has chemical stability.

The GKH sanitary centrifugal pump is widely used for conveying various liquid materials in such fields as dairy, beer, beverage, medicine, biological engineering, fine chemical industry, etc.

It can be used to convey ordinary solutions of low and medium viscosity, and solutions containing suspension or corrosive solutions.
