Sanitary Stainless Steel Liquid Ring Pump
Material : Stainless Steel 304 or 316L
Max Pressure: 5Bar
Connection : Clamp
100% tested and inspected
The SLRP sanitary liquid-ring pump is composed of motor, pump shaft,mechanical clamping jacket ,
sanitary mechanical seal, connection support ,rear plate impeller, pump shell, etc. It is a reflux pump specially designed for ClP.
It has the stainless steel protection cover used for protecting the motor,and the equipment is supported by four adjustable feet.
|
Name |
Sanitary Stainless Steel Liquid Ring Pump |
|
Material |
Stainless Steel 304 or 316L |
|
Max Flow Rate |
40m3/h |
|
Mechanical Seal |
C/SIC/EPDM |
|
Max Suction |
8m, 22ft |
|
Max Pressure |
5 Bar |
|
Working Temperature |
-20°C ~ +130°C |
|
Inlet/Outlet Connection |
Tri-Clamp End, Butt Weld End, Thread, Flange |
|
Surface |
Ra16-32µin (0.4-0.8µm) |
|
Package |
Foam bag/shrink bag-carton box-ply woodencase |
Shaft seal
The SLRP sanitary pump is provided with a set of externally mounted single end mechanical seal.
The static ring of the mechanical seal is made of stainless steel, silicon carbide or tungsten alloy.
The dynamic ring is made of stainless steel, carbon, graphite or tungsten alloy.
