Sanitary Stainless Steel Top Entry Bag Filter
Material : Stainless Steel 304 or 316L
Max Operate Pressure: 10Bar
100% tested and inspected
Single bag filter with the most reasonable structure
Top Entry Bag Filter Housing for some coarse filtration and pre-filteration process.
The desian of side entry first and then top entry into the filter bag does not cause turbulence and not reduce pressure because of the stabled pressure.
Also this structure effectively protects the filter bag.
The top cover is fully pressed and sealed, and the sealing effect is better.
|
Name |
Sanitary Stainless Steel Top Entry Bag Filter |
|
Material |
Stainless steel 304, 316L |
|
Inlet/Out Dimension |
1"- 4" |
|
Filter Bag type |
1#Bag, 2#Bag, 3#Bag, 4#Bag |
|
O-ring |
EPDM, PTFE, Viton, Silicone |
|
Surface |
Mirror Polish,Matt Polish, Electrolytical Polish, Mechanical polishing,Acid Washing,Sand blasting |
|
Max. operating pressure |
10Bar |
|
Max. operating temperature |
150°C |
|
Way of Connection |
Tri-Clover/Clamp End,Thread End,Butt Weld End,Flanged |
|
Package |
Foam bag/shrink bag-carton box-ply woodencase |
Food and Beverage Processing
It plays a critical role in the food and beverage industry by filtering ingredients like raw materials, additives, and flavorings.
Filtration of Liquids
Sanitary filter housing is used to filter liquids including water, juices, wine, beer, and dairy products
Cosmetics and Personal Care
It is utilized in manufacturing processes to remove impurities, particles, and contaminants from cosmetic and personal care product formulations.
Sterile Filtration
In pharmaceutical and biotechnology sectors, it is employed for sterile filtration of biopharmaceutical products, vaccines, antibiotics, and other sensitive pharmaceutical solutions.
Process Water Filtration
Sanitary filter housing filters water used in various industrial processes, such as cooling systems, boilers, and production lines.
